#27 Le 07/01/2016, à 10:53
- filipino
Re : [Résolu] Installation dualboot sur laptop sous wds10
Bonjour,
Bougron, je viens juste de voir ton post #17, et comme je disais, pour passer en mode EFI je n'ai vu que ça : " Launch EFI shell from filesystem device", sinon rien d'aitre avec wds10
Laptop ASUS X751LAV-TY481T
XUbuntu 18.04 LTS- 64 bits - i3 - 4005U-1.70ghz
Hors ligne
#28 Le 07/01/2016, à 12:21
- Bougron
Re : [Résolu] Installation dualboot sur laptop sous wds10
Bonjour
J'ai récupéré le mode d'emploi http://dlcdnet.asus.com/pub/ASUS/nb/X75 … 1_V5_A.pdf
A la page 71
Il faut que tu regardes si "launch CSM" est toujours positionné sur 'disable'
si "fast boot" est bien mis sur "disable"
il y a aussi la ligne
"add a new boot option " => à voir ce que cela donne (la clé USB étant déjà branchée)
A la page 79, il y a aussi "USB configuration"
Je ne sais pas ce que cela cache. Peut-être le fait de booter en LEGACY/CSM prioritairement alors qu'il faut EFI.
Je ne sais pas si tout le monde sera comme moi, Mais je n'arrive pas à agrandir l'image que tu as postée. Si bien que je ne peux pas la lire correctement.
Dernière modification par Bougron (Le 07/01/2016, à 15:42)
Hors ligne
#29 Le 07/01/2016, à 15:28
- filipino
Re : [Résolu] Installation dualboot sur laptop sous wds10
Pour le mode d'emploi, eh bien ce n'est visiblement pas prévu au programme!
je peux refaire des images si besoin, mais comme je disais à part " Launch EFI shell from filesystem device" , EFI n'apparait nulle part. Alors, pardon d'insister mais : que veut dire cette phrase??? je lance ou pas?
Dernière modification par filipino (Le 07/01/2016, à 15:45)
Laptop ASUS X751LAV-TY481T
XUbuntu 18.04 LTS- 64 bits - i3 - 4005U-1.70ghz
Hors ligne
#30 Le 07/01/2016, à 15:47
- Bougron
Re : [Résolu] Installation dualboot sur laptop sous wds10
peux-tu répondre à cela
A la page 71
Il faut que tu regardes si "launch CSM" est toujours positionné sur 'disable'
si "fast boot" est bien mis sur "disable"
car si lauch CSM est positionné sur disable, cela veux dire que le boot EFI est opérationnel, Sinon ce n'est pas le cas.
Tu peux refaire des photos, mais il faut que je sois capable de les agrandir pour bien les lire.
Hors ligne
#31 Le 07/01/2016, à 16:03
- malbo
Re : [Résolu] Installation dualboot sur laptop sous wds10
Moi non plus je n'arrive pas à agrandir l'image du post #26. Je crois distinguer une ligne "CD/DVD MDM Drive BBS priorities". Peux-tu cliquer sur cette ligne et prendre une photo de ce que ça fait apparaître ?
Hors ligne
#33 Le 07/01/2016, à 18:05
- Bougron
Re : [Résolu] Installation dualboot sur laptop sous wds10
Bonjour
En faisant un gros effort de lecture, dans la première image, il me semble que c'est le boot de windows qui est mis prioritaire.
Je ne sais pas qui est l'autre, mais c'est peut-être le bon. Ou alors ton support de boot n'est pas efi.
Hors ligne
#34 Le 07/01/2016, à 18:10
- malbo
Re : [Résolu] Installation dualboot sur laptop sous wds10
Voici une ligne extraite de ton Boot-Info que j'ai collé dans le post #16 :
lrwxrwxrwx 1 root root 9 Jan 6 16:43 ata-TSSTcorp_CDDVDW_SU-228GB_S18G6YHG904V47 -> ../../sr0
On y voit "TSSTcorp_CDDVDW_SU-228GB" qui est relatif à ton lecteur optique puisqu'on peut voir "sr0" en fin de ligne (c'est un repère qui désigne classiquement le lecteur optique).
Dans ta 2ème photo du post #32, on peut apercevoir :
Boot Override
Windows Boot Manager
UEFI: TSSTcorp CDDVDW SU-228GB
Il faut que tu sélectionnes cette ligne "UEFI: TSSTcorp CDDVDW SU-228GB" et que tu démarres dessus parce que c'est celle qui permet de démarrer en mode EFI sur le lecteur optique.
Dernière modification par malbo (Le 07/01/2016, à 18:12)
Hors ligne
#35 Le 07/01/2016, à 18:21
- filipino
Re : [Résolu] Installation dualboot sur laptop sous wds10
Bien, je m'y colle, et pour info voici un mail envoyé par Asus suite à ma demande de booter sur dvd en mode EFI
1- Lors d'accès au BIOS, veuillez choisir l'onglet Boot.
2- Changer le Fast Boot en [Disabled ] puis sauvegardez avec F10.
Au redémarrage appuyer sur F2, sous l'onglet Boot, changer Launch CSM en [Enable] puis sauvegardez avec F10
3- Au redémarrage, en accédant au Bios, une ligne va s'ajouter avec Launch PXEOpROM [Disabled] (n'est pas à changer)
4- Veuillez accéder sur l'onglet Security
Changez Secure Boot control sur [Disabled] puis sauvegardez avec F10
5- Redémarrez le PC et accédez au Bios au menu BOOT
Changez la séquence Boot avec + / - puis sauvegardez avec F10 PC va booter sur le lecteur DVD ou sur la clé USB (selon votre choix)
Je suppose que je n'en tiens pas compte
Laptop ASUS X751LAV-TY481T
XUbuntu 18.04 LTS- 64 bits - i3 - 4005U-1.70ghz
Hors ligne
#36 Le 07/01/2016, à 18:24
- malbo
Re : [Résolu] Installation dualboot sur laptop sous wds10
Le mail d'Asus est une connerie (*). Je t'ai dit que faire dans mon post #34.
(*) la proposition débile du mail "Launch CSM en [Enable]" va rétablir le démarrage en mode Bios qui ne convient pas du tout puisqu'il faut que tu démarres en mode EFI sur le liveDVD (il faut que tu démarres sur l'entrée "UEFI: TSSTcorp CDDVDW SU-228GB", la chose importante étant "UEFI" qui apparaît en tête.
Dernière modification par malbo (Le 07/01/2016, à 18:28)
Hors ligne
#37 Le 07/01/2016, à 18:27
- filipino
Re : [Résolu] Installation dualboot sur laptop sous wds10
C'est ce qui me semblait, c'est lancé, j'ai bien l'écran avec "try ubuntu,etc"
Laptop ASUS X751LAV-TY481T
XUbuntu 18.04 LTS- 64 bits - i3 - 4005U-1.70ghz
Hors ligne
#38 Le 07/01/2016, à 18:30
- malbo
Re : [Résolu] Installation dualboot sur laptop sous wds10
c'est lancé, j'ai bien l'écran avec "try ubuntu,etc"
Depuis la session live, je te prie de refaire un Boot-Info et de donner l'URL de ce Boot-Info dans ta réponse afin qu'on puisse contrôler.
Dernière modification par malbo (Le 07/01/2016, à 18:31)
Hors ligne
#39 Le 07/01/2016, à 18:47
- filipino
Re : [Résolu] Installation dualboot sur laptop sous wds10
Ok voilà (il y a bien le sda1 en efi !
http://paste.ubuntu.com14431075/
Laptop ASUS X751LAV-TY481T
XUbuntu 18.04 LTS- 64 bits - i3 - 4005U-1.70ghz
Hors ligne
#40 Le 07/01/2016, à 19:01
- malbo
Re : [Résolu] Installation dualboot sur laptop sous wds10
Ton Boot-Info ( http://paste.ubuntu.com/14431075/ ) est là :
Boot Info Script e7fc706 + Boot-Repair extra info [Boot-Info 9Feb2015]
============================= Boot Info Summary: ===============================
=> No boot loader is installed in the MBR of /dev/sda.
sda1: __________________________________________________________________________
File system: vfat
Boot sector type: Windows 8/2012: FAT32
Boot sector info: No errors found in the Boot Parameter Block.
Operating System:
Boot files: /EFI/Boot/bootx64.efi /EFI/Microsoft/Boot/bootmgfw.efi
/EFI/Microsoft/Boot/bootmgr.efi
/EFI/Microsoft/Boot/memtest.efi
sda2: __________________________________________________________________________
File system:
Boot sector type: -
Boot sector info:
Mounting failed: mount: unknown filesystem type ''
sda3: __________________________________________________________________________
File system: ntfs
Boot sector type: Windows 8/2012: NTFS
Boot sector info: No errors found in the Boot Parameter Block.
Operating System:
Boot files: /bootmgr /Boot/BCD /Windows/System32/winload.exe
sda4: __________________________________________________________________________
File system: ntfs
Boot sector type: Windows 8/2012: NTFS
Boot sector info: No errors found in the Boot Parameter Block.
Operating System:
Boot files:
============================ Drive/Partition Info: =============================
Drive: sda _____________________________________________________________________
Disk /dev/sda: 1000.2 GB, 1000204886016 bytes
256 heads, 63 sectors/track, 121126 cylinders, total 1953525168 sectors
Units = sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 4096 bytes
Partition Boot Start Sector End Sector # of Sectors Id System
/dev/sda1 1 4,294,967,295 4,294,967,295 ee GPT
/dev/sda1 ends after the last sector of /dev/sda
GUID Partition Table detected.
Partition Start Sector End Sector # of Sectors System
/dev/sda1 2,048 534,527 532,480 EFI System partition
/dev/sda2 534,528 567,295 32,768 Microsoft Reserved Partition (Windows)
/dev/sda3 567,296 780,388,351 779,821,056 Data partition (Windows/Linux)
/dev/sda4 780,388,352 781,410,303 1,021,952 Windows Recovery Environment (Windows)
"blkid" output: ________________________________________________________________
Device UUID TYPE LABEL
/dev/loop0 squashfs
/dev/sda1 0C9C-F6D9 vfat SYSTEM
/dev/sda3 4A449F6F449F5C8F ntfs OS
/dev/sda4 28D4E8A9D4E87A88 ntfs RECOVERY
/dev/sr0 iso9660 Ubuntu 14.04.3 LTS amd64
========================= "ls -l /dev/disk/by-id" output: ======================
total 0
lrwxrwxrwx 1 root root 9 Jan 7 16:46 ata-TOSHIBA_MQ01ABD100_85UCC9BGT -> ../../sda
lrwxrwxrwx 1 root root 10 Jan 7 2016 ata-TOSHIBA_MQ01ABD100_85UCC9BGT-part1 -> ../../sda1
lrwxrwxrwx 1 root root 10 Jan 7 2016 ata-TOSHIBA_MQ01ABD100_85UCC9BGT-part2 -> ../../sda2
lrwxrwxrwx 1 root root 10 Jan 7 16:46 ata-TOSHIBA_MQ01ABD100_85UCC9BGT-part3 -> ../../sda3
lrwxrwxrwx 1 root root 10 Jan 7 16:46 ata-TOSHIBA_MQ01ABD100_85UCC9BGT-part4 -> ../../sda4
lrwxrwxrwx 1 root root 9 Jan 7 2016 ata-TSSTcorp_CDDVDW_SU-228GB_S18G6YHG904V47 -> ../../sr0
lrwxrwxrwx 1 root root 9 Jan 7 16:46 wwn-0x50000396738850cc -> ../../sda
lrwxrwxrwx 1 root root 10 Jan 7 2016 wwn-0x50000396738850cc-part1 -> ../../sda1
lrwxrwxrwx 1 root root 10 Jan 7 2016 wwn-0x50000396738850cc-part2 -> ../../sda2
lrwxrwxrwx 1 root root 10 Jan 7 16:46 wwn-0x50000396738850cc-part3 -> ../../sda3
lrwxrwxrwx 1 root root 10 Jan 7 16:46 wwn-0x50000396738850cc-part4 -> ../../sda4
================================ Mount points: =================================
Device Mount_Point Type Options
/dev/loop0 /rofs squashfs (ro,noatime)
/dev/sr0 /cdrom iso9660 (ro,noatime)
=============================== StdErr Messages: ===============================
File descriptor 9 (/proc/13617/mounts) leaked on lvs invocation. Parent PID 19219: bash
File descriptor 63 (pipe:[55156]) leaked on lvs invocation. Parent PID 19219: bash
No volume groups found
ADDITIONAL INFORMATION :
=================== log of boot-info 2016-01-07__16h46 ===================
boot-info version : 4ppa35
boot-sav version : 4ppa35
glade2script version : 3.2.2~ppa47~saucy
boot-sav-extra version : 4ppa35
boot-info is executed in live-session (Ubuntu 14.04.3 LTS, trusty, Ubuntu, x86_64)
CPU op-mode(s): 32-bit, 64-bit
BOOT_IMAGE=/casper/vmlinuz.efi file=/cdrom/preseed/ubuntu.seed boot=casper quiet splash --
ls: cannot access /home/usr/.config: No such file or directory
WARNING: GPT (GUID Partition Table) detected on '/dev/sda'! The util fdisk doesn't support GPT. Use GNU Parted.
=================== os-prober:
/dev/sda1@/efi/Microsoft/Boot/bootmgfw.efi:Windows Boot Manager:Windows:efi
=================== blkid:
/dev/sda1: LABEL="SYSTEM" UUID="0C9C-F6D9" TYPE="vfat"
/dev/sda3: LABEL="OS" UUID="4A449F6F449F5C8F" TYPE="ntfs"
/dev/sda4: LABEL="RECOVERY" UUID="28D4E8A9D4E87A88" TYPE="ntfs"
/dev/loop0: TYPE="squashfs"
/dev/sr0: LABEL="Ubuntu 14.04.3 LTS amd64" TYPE="iso9660"
1 disks with OS, 1 OS : 0 Linux, 0 MacOS, 1 Windows, 0 unknown type OS.
Windows not detected by os-prober on sda3.
WARNING: GPT (GUID Partition Table) detected on '/dev/sda'! The util sfdisk doesn't support GPT. Use GNU Parted.
WARNING: GPT (GUID Partition Table) detected on '/dev/sda'! The util fdisk doesn't support GPT. Use GNU Parted.
Presence of EFI/Microsoft file detected: /mnt/boot-sav/sda1/EFI/Microsoft/Boot/bootmgfw.efi
Presence of EFI/Boot file detected: /mnt/boot-sav/sda1/EFI/Boot/bootx64.efi
=================== efibootmgr -v
BootCurrent: 0002
Timeout: 2 seconds
BootOrder: 0002,0000
Boot0000* Windows Boot Manager HD(1,800,82000,2bfb34a2-8653-419c-90de-d535a11a2fc7)File(EFIMICROSOFTBOOTBOOTMGFW.EFI)WINDOWS.........x...B.C.D.O.B.J.E.C.T.=.{.9.d.e.a.8.6.2.c.-.5.c.d.d.-.4.e.7.0.-.a.c.c.1.-.f.3.2.b.3.4.4.d.4.7.9.5.}....................
Boot0002* UEFI: TSSTcorp CDDVDW SU-228GB ACPI(a0341d0,0)PCI(1f,2)03120a000100ffff0000CD-ROM(1,7c6fa,11c0)..BO
=================== UEFI/Legacy mode:
BIOS is EFI-compatible, and is setup in EFI-mode for this live-session.
SecureBoot disabled. (maybe sec-boot, Please report this message to boot.repair@gmail.com)
=================== PARTITIONS & DISKS:
sda1 : sda, not-sepboot, no-grubenv nogrub, no-docgrub, no-update-grub, 32, no-boot, is-os, is-correct-EFI, part-has-no-fstab, part-has-no-fstab, no-nt, no-winload, no-recov-nor-hid, no-bmgr, notwinboot, nopakmgr, nogrubinstall, no---usr, part-has-no-fstab, not-sep-usr, standard, not-far, /mnt/boot-sav/sda1.
sda3 : sda, not-sepboot, no-grubenv nogrub, no-docgrub, no-update-grub, 32, no-boot, is-os, not--efi--part, part-has-no-fstab, part-has-no-fstab, no-nt, haswinload, no-recov-nor-hid, bootmgr, is-winboot, nopakmgr, nogrubinstall, no---usr, part-has-no-fstab, not-sep-usr, standard, farbios, /mnt/boot-sav/sda3.
sda4 : sda, not-sepboot, no-grubenv nogrub, no-docgrub, no-update-grub, 32, no-boot, no-os, not--efi--part, part-has-no-fstab, part-has-no-fstab, no-nt, no-winload, recovery-or-hidden, no-bmgr, notwinboot, nopakmgr, nogrubinstall, no---usr, part-has-no-fstab, not-sep-usr, standard, farbios, /mnt/boot-sav/sda4.
sda : GPT, no-BIOS_boot, has-correctEFI, not-usb, has-os, 2048 sectors * 512 bytes
=================== parted -l:
Model: ATA TOSHIBA MQ01ABD1 (scsi)
Disk /dev/sda: 1000GB
Sector size (logical/physical): 512B/4096B
Partition Table: gpt
Number Start End Size File system Name Flags
1 1049kB 274MB 273MB fat32 EFI system partition boot
2 274MB 290MB 16.8MB Microsoft reserved partition msftres
3 290MB 400GB 399GB ntfs Basic data partition msftdata
4 400GB 400GB 523MB ntfs Basic data partition hidden, diag
Warning: Unable to open /dev/sr0 read-write (Read-only file system). /dev/sr0 has been opened read-only.
Error: Can't have a partition outside the disk!
=================== parted -lm:
BYT;
/dev/sda:1000GB:scsi:512:4096:gpt:ATA TOSHIBA MQ01ABD1;
1:1049kB:274MB:273MB:fat32:EFI system partition:boot;
2:274MB:290MB:16.8MB::Microsoft reserved partition:msftres;
3:290MB:400GB:399GB:ntfs:Basic data partition:msftdata;
4:400GB:400GB:523MB:ntfs:Basic data partition:hidden, diag;
Warning: Unable to open /dev/sr0 read-write (Read-only file system). /dev/sr0 has been opened read-only.
Error: Can't have a partition outside the disk!
=================== lsblk:
KNAME TYPE FSTYPE SIZE LABEL
sda disk 931.5G
sda1 part vfat 260M SYSTEM
sda2 part 16M
sda3 part ntfs 371.9G OS
sda4 part ntfs 499M RECOVERY
sr0 rom iso9660 1006M Ubuntu 14.04.3 LTS amd64
loop0 loop squashfs 962.1M
KNAME ROTA RO RM STATE MOUNTPOINT
sda 1 0 0 running
sda1 1 0 0 /mnt/boot-sav/sda1
sda2 1 0 0
sda3 1 0 0 /mnt/boot-sav/sda3
sda4 1 0 0 /mnt/boot-sav/sda4
sr0 1 0 1 running /cdrom
loop0 1 1 0 /rofs
=================== mount:
/cow on / type overlay (rw)
proc on /proc type proc (rw,noexec,nosuid,nodev)
sysfs on /sys type sysfs (rw,noexec,nosuid,nodev)
udev on /dev type devtmpfs (rw,mode=0755)
devpts on /dev/pts type devpts (rw,noexec,nosuid,gid=5,mode=0620)
tmpfs on /run type tmpfs (rw,noexec,nosuid,size=10%,mode=0755)
/dev/sr0 on /cdrom type iso9660 (ro,noatime)
/dev/loop0 on /rofs type squashfs (ro,noatime)
none on /sys/fs/cgroup type tmpfs (rw)
none on /sys/fs/fuse/connections type fusectl (rw)
none on /sys/kernel/debug type debugfs (rw)
none on /sys/kernel/security type securityfs (rw)
none on /sys/firmware/efi/efivars type efivarfs (rw)
tmpfs on /tmp type tmpfs (rw,nosuid,nodev)
none on /run/lock type tmpfs (rw,noexec,nosuid,nodev,size=5242880)
none on /run/shm type tmpfs (rw,nosuid,nodev)
none on /run/user type tmpfs (rw,noexec,nosuid,nodev,size=104857600,mode=0755)
none on /sys/fs/pstore type pstore (rw)
systemd on /sys/fs/cgroup/systemd type cgroup (rw,noexec,nosuid,nodev,none,name=systemd)
gvfsd-fuse on /run/user/999/gvfs type fuse.gvfsd-fuse (rw,nosuid,nodev,user=ubuntu)
tmpfs on /var/lib/polkit-1/localauthority/90-mandatory.d type tmpfs (rw)
/dev/sda1 on /mnt/boot-sav/sda1 type vfat (rw)
/dev/sda3 on /mnt/boot-sav/sda3 type fuseblk (rw,nosuid,nodev,allow_other,blksize=4096)
/dev/sda4 on /mnt/boot-sav/sda4 type fuseblk (rw,nosuid,nodev,allow_other,blksize=4096)
=================== ls:
/sys/block/sda (filtered): alignment_offset bdi capability dev device discard_alignment events events_async events_poll_msecs ext_range holders inflight power queue range removable ro sda1 sda2 sda3 sda4 size slaves stat subsystem trace uevent
/sys/block/sr0 (filtered): alignment_offset bdi capability dev device discard_alignment events events_async events_poll_msecs ext_range holders inflight power queue range removable ro size slaves stat subsystem trace uevent
/dev (filtered): autofs block bsg btrfs-control bus cdrom char console core cpu cpu_dma_latency cuse disk dri ecryptfs fb0 fd full fuse hpet i2c-0 i2c-1 i2c-2 i2c-3 i2c-4 i2c-5 i2c-6 i2c-7 input kmsg kvm log mapper mcelog media0 mei0 mem memory_bandwidth net network_latency network_throughput null port ppp psaux ptmx pts random rfkill rtc rtc0 sda sda1 sda2 sda3 sda4 sg0 sg1 shm snapshot snd sr0 stderr stdin stdout uhid uinput urandom v4l vfio vga_arbiter vhci vhost-net video0 zero
ls /dev/mapper: control
=================== hexdump -n512 -C /dev/sda1
00000000 eb 58 90 4d 53 44 4f 53 35 2e 30 00 02 08 fe 1b |.X.MSDOS5.0.....|
00000010 02 00 00 00 00 f8 00 00 3f 00 ff 00 00 08 00 00 |........?.......|
00000020 00 20 08 00 01 02 00 00 00 00 00 00 02 00 00 00 |. ..............|
00000030 01 00 06 00 00 00 00 00 00 00 00 00 00 00 00 00 |................|
00000040 80 01 29 d9 f6 9c 0c 4e 4f 20 4e 41 4d 45 20 20 |..)....NO NAME |
00000050 20 20 46 41 54 33 32 20 20 20 33 c9 8e d1 bc f4 | FAT32 3.....|
00000060 7b 8e c1 8e d9 bd 00 7c 88 56 40 88 4e 02 8a 56 |{......|.V@.N..V|
00000070 40 b4 41 bb aa 55 cd 13 72 10 81 fb 55 aa 75 0a |@.A..U..r...U.u.|
00000080 f6 c1 01 74 05 fe 46 02 eb 2d 8a 56 40 b4 08 cd |...t..F..-.V@...|
00000090 13 73 05 b9 ff ff 8a f1 66 0f b6 c6 40 66 0f b6 |.s......f...@f..|
000000a0 d1 80 e2 3f f7 e2 86 cd c0 ed 06 41 66 0f b7 c9 |...?.......Af...|
000000b0 66 f7 e1 66 89 46 f8 83 7e 16 00 75 39 83 7e 2a |f..f.F..~..u9.~*|
000000c0 00 77 33 66 8b 46 1c 66 83 c0 0c bb 00 80 b9 01 |.w3f.F.f........|
000000d0 00 e8 2c 00 e9 a8 03 a1 f8 7d 80 c4 7c 8b f0 ac |..,......}..|...|
000000e0 84 c0 74 17 3c ff 74 09 b4 0e bb 07 00 cd 10 eb |..t.<.t.........|
000000f0 ee a1 fa 7d eb e4 a1 7d 80 eb df 98 cd 16 cd 19 |...}...}........|
00000100 66 60 80 7e 02 00 0f 84 20 00 66 6a 00 66 50 06 |f`.~.... .fj.fP.|
00000110 53 66 68 10 00 01 00 b4 42 8a 56 40 8b f4 cd 13 |Sfh.....B.V@....|
00000120 66 58 66 58 66 58 66 58 eb 33 66 3b 46 f8 72 03 |fXfXfXfX.3f;F.r.|
00000130 f9 eb 2a 66 33 d2 66 0f b7 4e 18 66 f7 f1 fe c2 |..*f3.f..N.f....|
00000140 8a ca 66 8b d0 66 c1 ea 10 f7 76 1a 86 d6 8a 56 |..f..f....v....V|
00000150 40 8a e8 c0 e4 06 0a cc b8 01 02 cd 13 66 61 0f |@............fa.|
00000160 82 74 ff 81 c3 00 02 66 40 49 75 94 c3 42 4f 4f |.t.....f@Iu..BOO|
00000170 54 4d 47 52 20 20 20 20 00 00 00 00 00 00 00 00 |TMGR ........|
00000180 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 |................|
*
000001a0 00 00 00 00 00 00 00 00 00 00 00 00 0d 0a 44 69 |..............Di|
000001b0 73 6b 20 65 72 72 6f 72 ff 0d 0a 50 72 65 73 73 |sk error...Press|
000001c0 20 61 6e 79 20 6b 65 79 20 74 6f 20 72 65 73 74 | any key to rest|
000001d0 61 72 74 0d 0a 00 00 00 00 00 00 00 00 00 00 00 |art.............|
000001e0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 |................|
000001f0 00 00 00 00 00 00 00 00 ac 01 b9 01 00 00 55 aa |..............U.|
00000200
=================== hexdump -n512 -C /dev/sda3
00000000 eb 52 90 4e 54 46 53 20 20 20 20 00 02 08 00 00 |.R.NTFS .....|
00000010 00 00 00 00 00 f8 00 00 3f 00 ff 00 00 a8 08 00 |........?.......|
00000020 00 00 00 00 80 00 80 00 ff 1f 7b 2e 00 00 00 00 |..........{.....|
00000030 00 00 0c 00 00 00 00 00 02 00 00 00 00 00 00 00 |................|
00000040 f6 00 00 00 01 00 00 00 8f 5c 9f 44 6f 9f 44 4a |..........Do.DJ|
00000050 00 00 00 00 fa 33 c0 8e d0 bc 00 7c fb 68 c0 07 |.....3.....|.h..|
00000060 1f 1e 68 66 00 cb 88 16 0e 00 66 81 3e 03 00 4e |..hf......f.>..N|
00000070 54 46 53 75 15 b4 41 bb aa 55 cd 13 72 0c 81 fb |TFSu..A..U..r...|
00000080 55 aa 75 06 f7 c1 01 00 75 03 e9 dd 00 1e 83 ec |U.u.....u.......|
00000090 18 68 1a 00 b4 48 8a 16 0e 00 8b f4 16 1f cd 13 |.h...H..........|
000000a0 9f 83 c4 18 9e 58 1f 72 e1 3b 06 0b 00 75 db a3 |.....X.r.;...u..|
000000b0 0f 00 c1 2e 0f 00 04 1e 5a 33 db b9 00 20 2b c8 |........Z3... +.|
000000c0 66 ff 06 11 00 03 16 0f 00 8e c2 ff 06 16 00 e8 |f...............|
000000d0 4b 00 2b c8 77 ef b8 00 bb cd 1a 66 23 c0 75 2d |K.+.w......f#.u-|
000000e0 66 81 fb 54 43 50 41 75 24 81 f9 02 01 72 1e 16 |f..TCPAu$....r..|
000000f0 68 07 bb 16 68 52 11 16 68 09 00 66 53 66 53 66 |h...hR..h..fSfSf|
00000100 55 16 16 16 68 b8 01 66 61 0e 07 cd 1a 33 c0 bf |U...h..fa....3..|
00000110 0a 13 b9 f6 0c fc f3 aa e9 fe 01 90 90 66 60 1e |.............f`.|
00000120 06 66 a1 11 00 66 03 06 1c 00 1e 66 68 00 00 00 |.f...f.....fh...|
00000130 00 66 50 06 53 68 01 00 68 10 00 b4 42 8a 16 0e |.fP.Sh..h...B...|
00000140 00 16 1f 8b f4 cd 13 66 59 5b 5a 66 59 66 59 1f |.......fY[ZfYfY.|
00000150 0f 82 16 00 66 ff 06 11 00 03 16 0f 00 8e c2 ff |....f...........|
00000160 0e 16 00 75 bc 07 1f 66 61 c3 a1 f6 01 e8 09 00 |...u...fa.......|
00000170 a1 fa 01 e8 03 00 f4 eb fd 8b f0 ac 3c 00 74 09 |............<.t.|
00000180 b4 0e bb 07 00 cd 10 eb f2 c3 0d 0a 41 20 64 69 |............A di|
00000190 73 6b 20 72 65 61 64 20 65 72 72 6f 72 20 6f 63 |sk read error oc|
000001a0 63 75 72 72 65 64 00 0d 0a 42 4f 4f 54 4d 47 52 |curred...BOOTMGR|
000001b0 20 69 73 20 63 6f 6d 70 72 65 73 73 65 64 00 0d | is compressed..|
000001c0 0a 50 72 65 73 73 20 43 74 72 6c 2b 41 6c 74 2b |.Press Ctrl+Alt+|
000001d0 44 65 6c 20 74 6f 20 72 65 73 74 61 72 74 0d 0a |Del to restart..|
000001e0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 |................|
000001f0 00 00 00 00 00 00 8a 01 a7 01 bf 01 00 00 55 aa |..............U.|
00000200
=================== hexdump -n512 -C /dev/sda4
00000000 eb 52 90 4e 54 46 53 20 20 20 20 00 02 08 00 00 |.R.NTFS .....|
00000010 00 00 00 00 00 f8 00 00 3f 00 ff 00 00 c8 83 2e |........?.......|
00000020 00 00 00 00 80 00 80 00 ff 97 0f 00 00 00 00 00 |................|
00000030 55 a6 00 00 00 00 00 00 02 00 00 00 00 00 00 00 |U...............|
00000040 f6 00 00 00 01 00 00 00 88 7a e8 d4 a9 e8 d4 28 |.........z.....(|
00000050 00 00 00 00 fa 33 c0 8e d0 bc 00 7c fb 68 c0 07 |.....3.....|.h..|
00000060 1f 1e 68 66 00 cb 88 16 0e 00 66 81 3e 03 00 4e |..hf......f.>..N|
00000070 54 46 53 75 15 b4 41 bb aa 55 cd 13 72 0c 81 fb |TFSu..A..U..r...|
00000080 55 aa 75 06 f7 c1 01 00 75 03 e9 dd 00 1e 83 ec |U.u.....u.......|
00000090 18 68 1a 00 b4 48 8a 16 0e 00 8b f4 16 1f cd 13 |.h...H..........|
000000a0 9f 83 c4 18 9e 58 1f 72 e1 3b 06 0b 00 75 db a3 |.....X.r.;...u..|
000000b0 0f 00 c1 2e 0f 00 04 1e 5a 33 db b9 00 20 2b c8 |........Z3... +.|
000000c0 66 ff 06 11 00 03 16 0f 00 8e c2 ff 06 16 00 e8 |f...............|
000000d0 4b 00 2b c8 77 ef b8 00 bb cd 1a 66 23 c0 75 2d |K.+.w......f#.u-|
000000e0 66 81 fb 54 43 50 41 75 24 81 f9 02 01 72 1e 16 |f..TCPAu$....r..|
000000f0 68 07 bb 16 68 52 11 16 68 09 00 66 53 66 53 66 |h...hR..h..fSfSf|
00000100 55 16 16 16 68 b8 01 66 61 0e 07 cd 1a 33 c0 bf |U...h..fa....3..|
00000110 0a 13 b9 f6 0c fc f3 aa e9 fe 01 90 90 66 60 1e |.............f`.|
00000120 06 66 a1 11 00 66 03 06 1c 00 1e 66 68 00 00 00 |.f...f.....fh...|
00000130 00 66 50 06 53 68 01 00 68 10 00 b4 42 8a 16 0e |.fP.Sh..h...B...|
00000140 00 16 1f 8b f4 cd 13 66 59 5b 5a 66 59 66 59 1f |.......fY[ZfYfY.|
00000150 0f 82 16 00 66 ff 06 11 00 03 16 0f 00 8e c2 ff |....f...........|
00000160 0e 16 00 75 bc 07 1f 66 61 c3 a1 f6 01 e8 09 00 |...u...fa.......|
00000170 a1 fa 01 e8 03 00 f4 eb fd 8b f0 ac 3c 00 74 09 |............<.t.|
00000180 b4 0e bb 07 00 cd 10 eb f2 c3 0d 0a 41 20 64 69 |............A di|
00000190 73 6b 20 72 65 61 64 20 65 72 72 6f 72 20 6f 63 |sk read error oc|
000001a0 63 75 72 72 65 64 00 0d 0a 42 4f 4f 54 4d 47 52 |curred...BOOTMGR|
000001b0 20 69 73 20 63 6f 6d 70 72 65 73 73 65 64 00 0d | is compressed..|
000001c0 0a 50 72 65 73 73 20 43 74 72 6c 2b 41 6c 74 2b |.Press Ctrl+Alt+|
000001d0 44 65 6c 20 74 6f 20 72 65 73 74 61 72 74 0d 0a |Del to restart..|
000001e0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 |................|
000001f0 00 00 00 00 00 00 8a 01 a7 01 bf 01 00 00 55 aa |..............U.|
00000200
WARNING: GPT (GUID Partition Table) detected on '/dev/sda'! The util fdisk doesn't support GPT. Use GNU Parted.
=================== df -Th:
Filesystem Type Size Used Avail Use% Mounted on
/cow overlay 1.9G 124M 1.8G 7% /
udev devtmpfs 1.9G 12K 1.9G 1% /dev
tmpfs tmpfs 387M 1.4M 385M 1% /run
/dev/sr0 iso9660 1006M 1006M 0 100% /cdrom
/dev/loop0 squashfs 963M 963M 0 100% /rofs
none tmpfs 4.0K 0 4.0K 0% /sys/fs/cgroup
tmpfs tmpfs 1.9G 1.2M 1.9G 1% /tmp
none tmpfs 5.0M 4.0K 5.0M 1% /run/lock
none tmpfs 1.9G 80K 1.9G 1% /run/shm
none tmpfs 100M 68K 100M 1% /run/user
tmpfs tmpfs 1.9G 4.0K 1.9G 1% /var/lib/polkit-1/localauthority/90-mandatory.d
/dev/sda1 vfat 256M 26M 231M 10% /mnt/boot-sav/sda1
/dev/sda3 fuseblk 372G 68G 305G 19% /mnt/boot-sav/sda3
/dev/sda4 fuseblk 499M 330M 170M 66% /mnt/boot-sav/sda4
=================== fdisk -l:
Disk /dev/sda: 1000.2 GB, 1000204886016 bytes
256 heads, 63 sectors/track, 121126 cylinders, total 1953525168 sectors
Units = sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 4096 bytes
I/O size (minimum/optimal): 4096 bytes / 4096 bytes
Disk identifier: 0x796f89eb
Device Boot Start End Blocks Id System
/dev/sda1 1 4294967295 2147483647+ ee GPT
Partition 1 does not start on physical sector boundary.
No OS or WinEFI system
gui-tab-other.sh: line 94: _checkbutton_repairfilesystems: command not found
=================== Suggested repair
The default repair of the Boot-Repair utility would not act on the MBR.
Additional repair would be performed: repair-filesystems
=================== User settings
The settings chosen by the user will not act on the boot.
Oui, tu y es arrivé à démarrer en mode EFI. C'est mentionné clairement dans le Boot-Info (setup in EFI-mode for this live-session) :
=================== UEFI/Legacy mode:
BIOS is EFI-compatible, and is setup in EFI-mode for this live-session.
SecureBoot disabled. (maybe sec-boot, Please report this message to boot.repair@gmail.com)
Tu vas pouvoir faire l'installation avec l'aide du tuto "efi un jeu d'enfant"
Dernière modification par malbo (Le 07/01/2016, à 19:12)
Hors ligne
#41 Le 07/01/2016, à 19:52
- filipino
Re : [Résolu] Installation dualboot sur laptop sous wds10
Parfait, un grand merci, ça fonctionne parfaitement, je ne vois pas bien où a eu lieu le changement avec le choix EFI pour booter le dvd, (peut-être simplement un redémarrage?) en tout cas c'est bon!
Laptop ASUS X751LAV-TY481T
XUbuntu 18.04 LTS- 64 bits - i3 - 4005U-1.70ghz
Hors ligne
#42 Le 07/01/2016, à 20:02
- filipino
Re : [Résolu] Installation dualboot sur laptop sous wds10
PS : si vous avez des idées pour finaliser l'installation, merci
Laptop ASUS X751LAV-TY481T
XUbuntu 18.04 LTS- 64 bits - i3 - 4005U-1.70ghz
Hors ligne
#43 Le 07/01/2016, à 20:21
- malbo
Re : [Résolu] Installation dualboot sur laptop sous wds10
Peux-tu démarrer une session sur ton Ubuntu fraîchement installé, faire un Boot-Info depuis cette session et donner l'URL de de ce Boot-Info dans ta réponse ?
Hors ligne
#44 Le 07/01/2016, à 20:39
- filipino
Re : [Résolu] Installation dualboot sur laptop sous wds10
Laptop ASUS X751LAV-TY481T
XUbuntu 18.04 LTS- 64 bits - i3 - 4005U-1.70ghz
Hors ligne
#45 Le 07/01/2016, à 21:58
- malbo
Re : [Résolu] Installation dualboot sur laptop sous wds10
Ton dernier Boot-Info est là :
Boot Info Script e7fc706 + Boot-Repair extra info [Boot-Info 9Feb2015]
============================= Boot Info Summary: ===============================
=> No boot loader is installed in the MBR of /dev/sda.
sda1: __________________________________________________________________________
File system: vfat
Boot sector type: Windows 8/2012: FAT32
Boot sector info: No errors found in the Boot Parameter Block.
Operating System:
Boot files: /EFI/Boot/bootx64.efi /EFI/ubuntu/MokManager.efi
/EFI/ubuntu/grubx64.efi /EFI/ubuntu/shimx64.efi
/EFI/Microsoft/Boot/bootmgfw.efi
/EFI/Microsoft/Boot/bootmgr.efi
/EFI/Microsoft/Boot/memtest.efi
sda2: __________________________________________________________________________
File system:
Boot sector type: -
Boot sector info:
Mounting failed: mount: unknown filesystem type ''
sda3: __________________________________________________________________________
File system: ntfs
Boot sector type: Windows 8/2012: NTFS
Boot sector info: No errors found in the Boot Parameter Block.
Operating System:
Boot files: /bootmgr /Boot/BCD /Windows/System32/winload.exe
sda4: __________________________________________________________________________
File system: ntfs
Boot sector type: Windows 8/2012: NTFS
Boot sector info: No errors found in the Boot Parameter Block.
Operating System:
Boot files:
sda5: __________________________________________________________________________
File system: ext4
Boot sector type: -
Boot sector info:
Operating System: Ubuntu 14.04.3 LTS
Boot files: /boot/grub/grub.cfg /etc/fstab
sda6: __________________________________________________________________________
File system: swap
Boot sector type: -
Boot sector info:
============================ Drive/Partition Info: =============================
Drive: sda _____________________________________________________________________
Disk /dev/sda: 1000.2 GB, 1000204886016 bytes
255 heads, 63 sectors/track, 121601 cylinders, total 1953525168 sectors
Units = sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 4096 bytes
Partition Boot Start Sector End Sector # of Sectors Id System
/dev/sda1 1 1,953,525,167 1,953,525,167 ee GPT
GUID Partition Table detected.
Partition Start Sector End Sector # of Sectors System
/dev/sda1 2,048 534,527 532,480 EFI System partition
/dev/sda2 534,528 567,295 32,768 Microsoft Reserved Partition (Windows)
/dev/sda3 567,296 780,388,351 779,821,056 Data partition (Windows/Linux)
/dev/sda4 780,388,352 781,410,303 1,021,952 Windows Recovery Environment (Windows)
/dev/sda5 781,410,304 830,238,719 48,828,416 Data partition (Linux)
/dev/sda6 830,238,720 840,003,583 9,764,864 Swap partition (Linux)
"blkid" output: ________________________________________________________________
Device UUID TYPE LABEL
/dev/sda1 0C9C-F6D9 vfat SYSTEM
/dev/sda3 4A449F6F449F5C8F ntfs OS
/dev/sda4 28D4E8A9D4E87A88 ntfs RECOVERY
/dev/sda5 302572dd-6aef-4cb4-a40b-f375902408c7 ext4
/dev/sda6 46cb7994-259b-42d2-a82b-325c1bbbb2dc swap
========================= "ls -l /dev/disk/by-id" output: ======================
total 0
lrwxrwxrwx 1 root root 9 Jan 7 19:37 ata-TOSHIBA_MQ01ABD100_85UCC9BGT -> ../../sda
lrwxrwxrwx 1 root root 10 Jan 7 18:41 ata-TOSHIBA_MQ01ABD100_85UCC9BGT-part1 -> ../../sda1
lrwxrwxrwx 1 root root 10 Jan 7 18:41 ata-TOSHIBA_MQ01ABD100_85UCC9BGT-part2 -> ../../sda2
lrwxrwxrwx 1 root root 10 Jan 7 18:41 ata-TOSHIBA_MQ01ABD100_85UCC9BGT-part3 -> ../../sda3
lrwxrwxrwx 1 root root 10 Jan 7 19:37 ata-TOSHIBA_MQ01ABD100_85UCC9BGT-part4 -> ../../sda4
lrwxrwxrwx 1 root root 10 Jan 7 18:41 ata-TOSHIBA_MQ01ABD100_85UCC9BGT-part5 -> ../../sda5
lrwxrwxrwx 1 root root 10 Jan 7 18:41 ata-TOSHIBA_MQ01ABD100_85UCC9BGT-part6 -> ../../sda6
lrwxrwxrwx 1 root root 9 Jan 7 18:41 ata-TSSTcorp_CDDVDW_SU-228GB_S18G6YHG904V47 -> ../../sr0
lrwxrwxrwx 1 root root 9 Jan 7 19:37 wwn-0x50000396738850cc -> ../../sda
lrwxrwxrwx 1 root root 10 Jan 7 18:41 wwn-0x50000396738850cc-part1 -> ../../sda1
lrwxrwxrwx 1 root root 10 Jan 7 18:41 wwn-0x50000396738850cc-part2 -> ../../sda2
lrwxrwxrwx 1 root root 10 Jan 7 18:41 wwn-0x50000396738850cc-part3 -> ../../sda3
lrwxrwxrwx 1 root root 10 Jan 7 19:37 wwn-0x50000396738850cc-part4 -> ../../sda4
lrwxrwxrwx 1 root root 10 Jan 7 18:41 wwn-0x50000396738850cc-part5 -> ../../sda5
lrwxrwxrwx 1 root root 10 Jan 7 18:41 wwn-0x50000396738850cc-part6 -> ../../sda6
================================ Mount points: =================================
Device Mount_Point Type Options
/dev/sda1 /boot/efi vfat (rw)
/dev/sda3 /media/tati/OS fuseblk (rw,nosuid,nodev,allow_other,default_permissions,blksize=4096)
/dev/sda5 / ext4 (rw,errors=remount-ro)
=========================== sda5/boot/grub/grub.cfg: ===========================
--------------------------------------------------------------------------------
#
# DO NOT EDIT THIS FILE
#
# It is automatically generated by grub-mkconfig using templates
# from /etc/grub.d and settings from /etc/default/grub
#
### BEGIN /etc/grub.d/00_header ###
if [ -s $prefix/grubenv ]; then
set have_grubenv=true
load_env
fi
if [ "${next_entry}" ] ; then
set default="${next_entry}"
set next_entry=
save_env next_entry
set boot_once=true
else
set default="0"
fi
if [ x"${feature_menuentry_id}" = xy ]; then
menuentry_id_option="--id"
else
menuentry_id_option=""
fi
export menuentry_id_option
if [ "${prev_saved_entry}" ]; then
set saved_entry="${prev_saved_entry}"
save_env saved_entry
set prev_saved_entry=
save_env prev_saved_entry
set boot_once=true
fi
function savedefault {
if [ -z "${boot_once}" ]; then
saved_entry="${chosen}"
save_env saved_entry
fi
}
function recordfail {
set recordfail=1
if [ -n "${have_grubenv}" ]; then if [ -z "${boot_once}" ]; then save_env recordfail; fi; fi
}
function load_video {
if [ x$feature_all_video_module = xy ]; then
insmod all_video
else
insmod efi_gop
insmod efi_uga
insmod ieee1275_fb
insmod vbe
insmod vga
insmod video_bochs
insmod video_cirrus
fi
}
if [ x$feature_default_font_path = xy ] ; then
font=unicode
else
insmod part_gpt
insmod ext2
set root='hd0,gpt5'
if [ x$feature_platform_search_hint = xy ]; then
search --no-floppy --fs-uuid --set=root --hint-bios=hd0,gpt5 --hint-efi=hd0,gpt5 --hint-baremetal=ahci0,gpt5 302572dd-6aef-4cb4-a40b-f375902408c7
else
search --no-floppy --fs-uuid --set=root 302572dd-6aef-4cb4-a40b-f375902408c7
fi
font="/usr/share/grub/unicode.pf2"
fi
if loadfont $font ; then
set gfxmode=auto
load_video
insmod gfxterm
set locale_dir=$prefix/locale
set lang=fr_FR
insmod gettext
fi
terminal_output gfxterm
if [ "${recordfail}" = 1 ] ; then
set timeout=30
else
if [ x$feature_timeout_style = xy ] ; then
set timeout_style=menu
set timeout=10
# Fallback normal timeout code in case the timeout_style feature is
# unavailable.
else
set timeout=10
fi
fi
### END /etc/grub.d/00_header ###
### BEGIN /etc/grub.d/05_debian_theme ###
set menu_color_normal=white/black
set menu_color_highlight=black/light-gray
if background_color 44,0,30,0; then
clear
fi
### END /etc/grub.d/05_debian_theme ###
### BEGIN /etc/grub.d/10_linux ###
function gfxmode {
set gfxpayload="${1}"
if [ "${1}" = "keep" ]; then
set vt_handoff=vt.handoff=7
else
set vt_handoff=
fi
}
if [ "${recordfail}" != 1 ]; then
if [ -e ${prefix}/gfxblacklist.txt ]; then
if hwmatch ${prefix}/gfxblacklist.txt 3; then
if [ ${match} = 0 ]; then
set linux_gfx_mode=keep
else
set linux_gfx_mode=text
fi
else
set linux_gfx_mode=text
fi
else
set linux_gfx_mode=keep
fi
else
set linux_gfx_mode=text
fi
export linux_gfx_mode
menuentry 'Ubuntu' --class ubuntu --class gnu-linux --class gnu --class os $menuentry_id_option 'gnulinux-simple-302572dd-6aef-4cb4-a40b-f375902408c7' {
recordfail
load_video
gfxmode $linux_gfx_mode
insmod gzio
insmod part_gpt
insmod ext2
set root='hd0,gpt5'
if [ x$feature_platform_search_hint = xy ]; then
search --no-floppy --fs-uuid --set=root --hint-bios=hd0,gpt5 --hint-efi=hd0,gpt5 --hint-baremetal=ahci0,gpt5 302572dd-6aef-4cb4-a40b-f375902408c7
else
search --no-floppy --fs-uuid --set=root 302572dd-6aef-4cb4-a40b-f375902408c7
fi
linux /boot/vmlinuz-3.19.0-43-generic.efi.signed root=UUID=302572dd-6aef-4cb4-a40b-f375902408c7 ro quiet splash $vt_handoff
initrd /boot/initrd.img-3.19.0-43-generic
}
submenu 'Options avancées pour Ubuntu' $menuentry_id_option 'gnulinux-advanced-302572dd-6aef-4cb4-a40b-f375902408c7' {
menuentry 'Ubuntu, avec Linux 3.19.0-43-generic' --class ubuntu --class gnu-linux --class gnu --class os $menuentry_id_option 'gnulinux-3.19.0-43-generic-advanced-302572dd-6aef-4cb4-a40b-f375902408c7' {
recordfail
load_video
gfxmode $linux_gfx_mode
insmod gzio
insmod part_gpt
insmod ext2
set root='hd0,gpt5'
if [ x$feature_platform_search_hint = xy ]; then
search --no-floppy --fs-uuid --set=root --hint-bios=hd0,gpt5 --hint-efi=hd0,gpt5 --hint-baremetal=ahci0,gpt5 302572dd-6aef-4cb4-a40b-f375902408c7
else
search --no-floppy --fs-uuid --set=root 302572dd-6aef-4cb4-a40b-f375902408c7
fi
echo 'Chargement de Linux 3.19.0-43-generic…'
linux /boot/vmlinuz-3.19.0-43-generic.efi.signed root=UUID=302572dd-6aef-4cb4-a40b-f375902408c7 ro quiet splash $vt_handoff
echo 'Chargement du disque mémoire initial…'
initrd /boot/initrd.img-3.19.0-43-generic
}
menuentry 'Ubuntu, with Linux 3.19.0-43-generic (recovery mode)' --class ubuntu --class gnu-linux --class gnu --class os $menuentry_id_option 'gnulinux-3.19.0-43-generic-recovery-302572dd-6aef-4cb4-a40b-f375902408c7' {
recordfail
load_video
insmod gzio
insmod part_gpt
insmod ext2
set root='hd0,gpt5'
if [ x$feature_platform_search_hint = xy ]; then
search --no-floppy --fs-uuid --set=root --hint-bios=hd0,gpt5 --hint-efi=hd0,gpt5 --hint-baremetal=ahci0,gpt5 302572dd-6aef-4cb4-a40b-f375902408c7
else
search --no-floppy --fs-uuid --set=root 302572dd-6aef-4cb4-a40b-f375902408c7
fi
echo 'Chargement de Linux 3.19.0-43-generic…'
linux /boot/vmlinuz-3.19.0-43-generic.efi.signed root=UUID=302572dd-6aef-4cb4-a40b-f375902408c7 ro recovery nomodeset
echo 'Chargement du disque mémoire initial…'
initrd /boot/initrd.img-3.19.0-43-generic
}
menuentry 'Ubuntu, avec Linux 3.19.0-25-generic' --class ubuntu --class gnu-linux --class gnu --class os $menuentry_id_option 'gnulinux-3.19.0-25-generic-advanced-302572dd-6aef-4cb4-a40b-f375902408c7' {
recordfail
load_video
gfxmode $linux_gfx_mode
insmod gzio
insmod part_gpt
insmod ext2
set root='hd0,gpt5'
if [ x$feature_platform_search_hint = xy ]; then
search --no-floppy --fs-uuid --set=root --hint-bios=hd0,gpt5 --hint-efi=hd0,gpt5 --hint-baremetal=ahci0,gpt5 302572dd-6aef-4cb4-a40b-f375902408c7
else
search --no-floppy --fs-uuid --set=root 302572dd-6aef-4cb4-a40b-f375902408c7
fi
echo 'Chargement de Linux 3.19.0-25-generic…'
linux /boot/vmlinuz-3.19.0-25-generic root=UUID=302572dd-6aef-4cb4-a40b-f375902408c7 ro quiet splash $vt_handoff
echo 'Chargement du disque mémoire initial…'
initrd /boot/initrd.img-3.19.0-25-generic
}
menuentry 'Ubuntu, with Linux 3.19.0-25-generic (recovery mode)' --class ubuntu --class gnu-linux --class gnu --class os $menuentry_id_option 'gnulinux-3.19.0-25-generic-recovery-302572dd-6aef-4cb4-a40b-f375902408c7' {
recordfail
load_video
insmod gzio
insmod part_gpt
insmod ext2
set root='hd0,gpt5'
if [ x$feature_platform_search_hint = xy ]; then
search --no-floppy --fs-uuid --set=root --hint-bios=hd0,gpt5 --hint-efi=hd0,gpt5 --hint-baremetal=ahci0,gpt5 302572dd-6aef-4cb4-a40b-f375902408c7
else
search --no-floppy --fs-uuid --set=root 302572dd-6aef-4cb4-a40b-f375902408c7
fi
echo 'Chargement de Linux 3.19.0-25-generic…'
linux /boot/vmlinuz-3.19.0-25-generic root=UUID=302572dd-6aef-4cb4-a40b-f375902408c7 ro recovery nomodeset
echo 'Chargement du disque mémoire initial…'
initrd /boot/initrd.img-3.19.0-25-generic
}
}
### END /etc/grub.d/10_linux ###
### BEGIN /etc/grub.d/20_linux_xen ###
### END /etc/grub.d/20_linux_xen ###
### BEGIN /etc/grub.d/20_memtest86+ ###
### END /etc/grub.d/20_memtest86+ ###
### BEGIN /etc/grub.d/30_os-prober ###
menuentry 'Windows Boot Manager (sur /dev/sda1)' --class windows --class os $menuentry_id_option 'osprober-efi-0C9C-F6D9' {
insmod part_gpt
insmod fat
set root='hd0,gpt1'
if [ x$feature_platform_search_hint = xy ]; then
search --no-floppy --fs-uuid --set=root --hint-bios=hd0,gpt1 --hint-efi=hd0,gpt1 --hint-baremetal=ahci0,gpt1 0C9C-F6D9
else
search --no-floppy --fs-uuid --set=root 0C9C-F6D9
fi
chainloader /EFI/Microsoft/Boot/bootmgfw.efi
}
set timeout_style=menu
if [ "${timeout}" = 0 ]; then
set timeout=10
fi
### END /etc/grub.d/30_os-prober ###
### BEGIN /etc/grub.d/30_uefi-firmware ###
menuentry 'System setup' $menuentry_id_option 'uefi-firmware' {
fwsetup
}
### END /etc/grub.d/30_uefi-firmware ###
### BEGIN /etc/grub.d/40_custom ###
# This file provides an easy way to add custom menu entries. Simply type the
# menu entries you want to add after this comment. Be careful not to change
# the 'exec tail' line above.
### END /etc/grub.d/40_custom ###
### BEGIN /etc/grub.d/41_custom ###
if [ -f ${config_directory}/custom.cfg ]; then
source ${config_directory}/custom.cfg
elif [ -z "${config_directory}" -a -f $prefix/custom.cfg ]; then
source $prefix/custom.cfg;
fi
### END /etc/grub.d/41_custom ###
--------------------------------------------------------------------------------
=============================== sda5/etc/fstab: ================================
--------------------------------------------------------------------------------
# /etc/fstab: static file system information.
#
# Use 'blkid' to print the universally unique identifier for a
# device; this may be used with UUID= as a more robust way to name devices
# that works even if disks are added and removed. See fstab(5).
#
# <file system> <mount point> <type> <options> <dump> <pass>
# / was on /dev/sda5 during installation
UUID=302572dd-6aef-4cb4-a40b-f375902408c7 / ext4 errors=remount-ro 0 1
# /boot/efi was on /dev/sda1 during installation
UUID=0C9C-F6D9 /boot/efi vfat defaults 0 1
# swap was on /dev/sda6 during installation
UUID=46cb7994-259b-42d2-a82b-325c1bbbb2dc none swap sw 0 0
--------------------------------------------------------------------------------
ADDITIONAL INFORMATION :
=================== log of boot-info 2016-01-07__19h37 ===================
boot-info version : 4ppa35
boot-sav version : 4ppa35
glade2script version : 3.2.2~ppa47~saucy
boot-sav-extra version : 4ppa35
boot-info is executed in installed-session (Ubuntu 14.04.3 LTS, trusty, Ubuntu, x86_64)
CPU op-mode(s): 32-bit, 64-bit
BOOT_IMAGE=/boot/vmlinuz-3.19.0-43-generic.efi.signed root=UUID=302572dd-6aef-4cb4-a40b-f375902408c7 ro quiet splash vt.handoff=7
WARNING: GPT (GUID Partition Table) detected on '/dev/sda'! The util fdisk doesn't support GPT. Use GNU Parted.
=================== os-prober:
/dev/sda5:L'OS actuellement utilisé - Ubuntu 14.04.3 LTS CurrentSession:linux
/dev/sda1@/EFI/Microsoft/Boot/bootmgfw.efi:Windows Boot Manager:Windows:efi
=================== blkid:
/dev/sda1: LABEL="SYSTEM" UUID="0C9C-F6D9" TYPE="vfat"
/dev/sda3: LABEL="OS" UUID="4A449F6F449F5C8F" TYPE="ntfs"
/dev/sda4: LABEL="RECOVERY" UUID="28D4E8A9D4E87A88" TYPE="ntfs"
/dev/sda5: UUID="302572dd-6aef-4cb4-a40b-f375902408c7" TYPE="ext4"
/dev/sda6: UUID="46cb7994-259b-42d2-a82b-325c1bbbb2dc" TYPE="swap"
1 disks with OS, 2 OS : 1 Linux, 0 MacOS, 1 Windows, 0 unknown type OS.
Windows not detected by os-prober on sda3.
Attention : identifiant de table de partitions GPT (GUID) détecté sur « /dev/sda ». L'utilitaire sfdisk ne prend pas GPT en charge. Utilisez GNU Parted.
WARNING: GPT (GUID Partition Table) detected on '/dev/sda'! The util fdisk doesn't support GPT. Use GNU Parted.
=================== /etc/grub.d/ :
drwxr-xr-x 2 root root 4096 janv. 7 18:17 grub.d
total 76
-rwxr-xr-x 1 root root 9791 déc. 17 16:00 00_header
-rwxr-xr-x 1 root root 6058 mai 13 2015 05_debian_theme
-rwxr-xr-x 1 root root 11608 juin 26 2015 10_linux
-rwxr-xr-x 1 root root 10412 juin 26 2015 20_linux_xen
-rwxr-xr-x 1 root root 1992 mars 12 2014 20_memtest86+
-rwxr-xr-x 1 root root 11692 juin 26 2015 30_os-prober
-rwxr-xr-x 1 root root 1416 juin 26 2015 30_uefi-firmware
-rwxr-xr-x 1 root root 214 juin 26 2015 40_custom
-rwxr-xr-x 1 root root 216 juin 26 2015 41_custom
-rw-r--r-- 1 root root 483 juin 26 2015 README
=================== /etc/default/grub :
# If you change this file, run 'update-grub' afterwards to update
# /boot/grub/grub.cfg.
# For full documentation of the options in this file, see:
# info -f grub -n 'Simple configuration'
GRUB_DEFAULT=0
#GRUB_HIDDEN_TIMEOUT=0
GRUB_HIDDEN_TIMEOUT_QUIET=true
GRUB_TIMEOUT=10
GRUB_DISTRIBUTOR=`lsb_release -i -s 2> /dev/null || echo Debian`
GRUB_CMDLINE_LINUX_DEFAULT="quiet splash"
GRUB_CMDLINE_LINUX=""
# Uncomment to enable BadRAM filtering, modify to suit your needs
# This works with Linux (no patch required) and with any kernel that obtains
# the memory map information from GRUB (GNU Mach, kernel of FreeBSD ...)
#GRUB_BADRAM="0x01234567,0xfefefefe,0x89abcdef,0xefefefef"
# Uncomment to disable graphical terminal (grub-pc only)
#GRUB_TERMINAL=console
# The resolution used on graphical terminal
# note that you can use only modes which your graphic card supports via VBE
# you can see them in real GRUB with the command `vbeinfo'
#GRUB_GFXMODE=640x480
# Uncomment if you don't want GRUB to pass "root=UUID=xxx" parameter to Linux
#GRUB_DISABLE_LINUX_UUID=true
# Uncomment to disable generation of recovery mode menu entries
#GRUB_DISABLE_RECOVERY="true"
# Uncomment to get a beep at grub start
#GRUB_INIT_TUNE="480 440 1"
/boot/efi detected in the fstab of sda5: UUID=0C9C-F6D9 (sda1)
Presence of EFI/Microsoft file detected: /boot/efi/EFI/Microsoft/Boot/bootmgfw.efi
Presence of EFI/Boot file detected: /boot/efi/EFI/Boot/bootx64.efi
=================== efibootmgr -v
BootCurrent: 0001
Timeout: 2 seconds
BootOrder: 0001,0000,0002
Boot0000* Windows Boot Manager HD(1,800,82000,2bfb34a2-8653-419c-90de-d535a11a2fc7)File(EFIMICROSOFTBOOTBOOTMGFW.EFI)WINDOWS.........x...B.C.D.O.B.J.E.C.T.=.{.9.d.e.a.8.6.2.c.-.5.c.d.d.-.4.e.7.0.-.a.c.c.1.-.f.3.2.b.3.4.4.d.4.7.9.5.}....................
Boot0001* ubuntu HD(1,800,82000,2bfb34a2-8653-419c-90de-d535a11a2fc7)File(EFIUBUNTUSHIMX64.EFI)
Boot0002* ubuntu HD(1,800,82000,2bfb34a2-8653-419c-90de-d535a11a2fc7)File(EFIUBUNTUGRUBX64.EFI)..BO
=================== UEFI/Legacy mode:
BIOS is EFI-compatible, and is setup in EFI-mode for this installed-session.
SecureBoot disabled. (maybe sec-boot, Veuillez indiquer ce message à boot.repair@gmail.com)
=================== PARTITIONS & DISKS:
sda5 : sda, not-sepboot, grubenv-ok grub2, signed grub-efi , update-grub, 64, with-boot, is-os, not--efi--part, fstab-without-boot, fstab-has-goodEFI, no-nt, no-winload, no-recov-nor-hid, no-bmgr, notwinboot, apt-get, grub-install, with--usr, fstab-without-usr, not-sep-usr, standard, farbios, .
sda1 : sda, not-sepboot, no-grubenv nogrub, no-docgrub, no-update-grub, 32, no-boot, is-os, is-correct-EFI, part-has-no-fstab, part-has-no-fstab, no-nt, no-winload, no-recov-nor-hid, no-bmgr, notwinboot, nopakmgr, nogrubinstall, no---usr, part-has-no-fstab, not-sep-usr, standard, not-far, /boot/efi.
sda3 : sda, not-sepboot, no-grubenv nogrub, no-docgrub, no-update-grub, 32, no-boot, is-os, not--efi--part, part-has-no-fstab, part-has-no-fstab, no-nt, haswinload, no-recov-nor-hid, bootmgr, is-winboot, nopakmgr, nogrubinstall, no---usr, part-has-no-fstab, not-sep-usr, standard, farbios, /media/tati/OS.
sda4 : sda, not-sepboot, no-grubenv nogrub, no-docgrub, no-update-grub, 32, no-boot, no-os, not--efi--part, part-has-no-fstab, part-has-no-fstab, no-nt, no-winload, recovery-or-hidden, no-bmgr, notwinboot, nopakmgr, nogrubinstall, no---usr, part-has-no-fstab, not-sep-usr, standard, farbios, /mnt/boot-sav/sda4.
sda : GPT, no-BIOS_boot, has-correctEFI, not-usb, has-os, 2048 sectors * 512 bytes
=================== parted -l:
Model: ATA TOSHIBA MQ01ABD1 (scsi)
Disk /dev/sda: 1000GB
Sector size (logical/physical): 512B/4096B
Partition Table: gpt
Number Start End Size File system Name Flags
1 1049kB 274MB 273MB fat32 EFI system partition boot
2 274MB 290MB 16.8MB Microsoft reserved partition msftres
3 290MB 400GB 399GB ntfs Basic data partition msftdata
4 400GB 400GB 523MB ntfs Basic data partition hidden, diag
5 400GB 425GB 25.0GB ext4
6 425GB 430GB 5000MB linux-swap(v1)
=================== parted -lm:
BYT;
/dev/sda:1000GB:scsi:512:4096:gpt:ATA TOSHIBA MQ01ABD1;
1:1049kB:274MB:273MB:fat32:EFI system partition:boot;
2:274MB:290MB:16.8MB::Microsoft reserved partition:msftres;
3:290MB:400GB:399GB:ntfs:Basic data partition:msftdata;
4:400GB:400GB:523MB:ntfs:Basic data partition:hidden, diag;
5:400GB:425GB:25.0GB:ext4::;
6:425GB:430GB:5000MB:linux-swap(v1)::;
=================== lsblk:
KNAME TYPE FSTYPE SIZE LABEL
sda disk 931,5G
sda1 part vfat 260M SYSTEM
sda2 part 16M
sda3 part ntfs 371,9G OS
sda4 part ntfs 499M RECOVERY
sda5 part ext4 23,3G
sda6 part swap 4,7G
sr0 rom 1024M
KNAME ROTA RO RM STATE MOUNTPOINT
sda 1 0 0 running
sda1 1 0 0 /boot/efi
sda2 1 0 0
sda3 1 0 0 /media/tati/OS
sda4 1 0 0 /mnt/boot-sav/sda4
sda5 1 0 0 /
sda6 1 0 0 [SWAP]
sr0 1 0 1 running
=================== mount:
/dev/sda5 on / type ext4 (rw,errors=remount-ro)
proc on /proc type proc (rw,noexec,nosuid,nodev)
sysfs on /sys type sysfs (rw,noexec,nosuid,nodev)
none on /sys/fs/cgroup type tmpfs (rw)
none on /sys/fs/fuse/connections type fusectl (rw)
none on /sys/kernel/debug type debugfs (rw)
none on /sys/kernel/security type securityfs (rw)
none on /sys/firmware/efi/efivars type efivarfs (rw)
udev on /dev type devtmpfs (rw,mode=0755)
devpts on /dev/pts type devpts (rw,noexec,nosuid,gid=5,mode=0620)
tmpfs on /run type tmpfs (rw,noexec,nosuid,size=10%,mode=0755)
none on /run/lock type tmpfs (rw,noexec,nosuid,nodev,size=5242880)
none on /run/shm type tmpfs (rw,nosuid,nodev)
none on /run/user type tmpfs (rw,noexec,nosuid,nodev,size=104857600,mode=0755)
none on /sys/fs/pstore type pstore (rw)
/dev/sda1 on /boot/efi type vfat (rw)
systemd on /sys/fs/cgroup/systemd type cgroup (rw,noexec,nosuid,nodev,none,name=systemd)
gvfsd-fuse on /run/user/1000/gvfs type fuse.gvfsd-fuse (rw,nosuid,nodev,user=tati)
/dev/sda3 on /media/tati/OS type fuseblk (rw,nosuid,nodev,allow_other,default_permissions,blksize=4096)
/dev/sda4 on /mnt/boot-sav/sda4 type fuseblk (rw,nosuid,nodev,allow_other,blksize=4096)
=================== ls:
/sys/block/sda (filtered): alignment_offset bdi capability dev device discard_alignment events events_async events_poll_msecs ext_range holders inflight power queue range removable ro sda1 sda2 sda3 sda4 sda5 sda6 size slaves stat subsystem trace uevent
/sys/block/sr0 (filtered): alignment_offset bdi capability dev device discard_alignment events events_async events_poll_msecs ext_range holders inflight power queue range removable ro size slaves stat subsystem trace uevent
/dev (filtered): autofs block bsg btrfs-control bus cdrom char console core cpu cpu_dma_latency cuse disk dri ecryptfs fb0 fd full fuse hpet i2c-0 i2c-1 i2c-2 i2c-3 i2c-4 i2c-5 i2c-6 i2c-7 input kmsg kvm log mapper mcelog media0 mei0 mem memory_bandwidth net network_latency network_throughput null port ppp psaux ptmx pts random rfkill rtc rtc0 sda sda1 sda2 sda3 sda4 sda5 sda6 sg0 sg1 shm snapshot snd sr0 stderr stdin stdout uhid uinput urandom v4l vfio vga_arbiter vhci vhost-net video0 zero
ls /dev/mapper: control
ls: impossible d'accéder à : Aucun fichier ou dossier de ce type
=================== hexdump -n512 -C /dev/sda1
00000000 eb 58 90 4d 53 44 4f 53 35 2e 30 00 02 08 fe 1b |.X.MSDOS5.0.....|
00000010 02 00 00 00 00 f8 00 00 3f 00 ff 00 00 08 00 00 |........?.......|
00000020 00 20 08 00 01 02 00 00 00 00 00 00 02 00 00 00 |. ..............|
00000030 01 00 06 00 00 00 00 00 00 00 00 00 00 00 00 00 |................|
00000040 80 01 29 d9 f6 9c 0c 4e 4f 20 4e 41 4d 45 20 20 |..)....NO NAME |
00000050 20 20 46 41 54 33 32 20 20 20 33 c9 8e d1 bc f4 | FAT32 3.....|
00000060 7b 8e c1 8e d9 bd 00 7c 88 56 40 88 4e 02 8a 56 |{......|.V@.N..V|
00000070 40 b4 41 bb aa 55 cd 13 72 10 81 fb 55 aa 75 0a |@.A..U..r...U.u.|
00000080 f6 c1 01 74 05 fe 46 02 eb 2d 8a 56 40 b4 08 cd |...t..F..-.V@...|
00000090 13 73 05 b9 ff ff 8a f1 66 0f b6 c6 40 66 0f b6 |.s......f...@f..|
000000a0 d1 80 e2 3f f7 e2 86 cd c0 ed 06 41 66 0f b7 c9 |...?.......Af...|
000000b0 66 f7 e1 66 89 46 f8 83 7e 16 00 75 39 83 7e 2a |f..f.F..~..u9.~*|
000000c0 00 77 33 66 8b 46 1c 66 83 c0 0c bb 00 80 b9 01 |.w3f.F.f........|
000000d0 00 e8 2c 00 e9 a8 03 a1 f8 7d 80 c4 7c 8b f0 ac |..,......}..|...|
000000e0 84 c0 74 17 3c ff 74 09 b4 0e bb 07 00 cd 10 eb |..t.<.t.........|
000000f0 ee a1 fa 7d eb e4 a1 7d 80 eb df 98 cd 16 cd 19 |...}...}........|
00000100 66 60 80 7e 02 00 0f 84 20 00 66 6a 00 66 50 06 |f`.~.... .fj.fP.|
00000110 53 66 68 10 00 01 00 b4 42 8a 56 40 8b f4 cd 13 |Sfh.....B.V@....|
00000120 66 58 66 58 66 58 66 58 eb 33 66 3b 46 f8 72 03 |fXfXfXfX.3f;F.r.|
00000130 f9 eb 2a 66 33 d2 66 0f b7 4e 18 66 f7 f1 fe c2 |..*f3.f..N.f....|
00000140 8a ca 66 8b d0 66 c1 ea 10 f7 76 1a 86 d6 8a 56 |..f..f....v....V|
00000150 40 8a e8 c0 e4 06 0a cc b8 01 02 cd 13 66 61 0f |@............fa.|
00000160 82 74 ff 81 c3 00 02 66 40 49 75 94 c3 42 4f 4f |.t.....f@Iu..BOO|
00000170 54 4d 47 52 20 20 20 20 00 00 00 00 00 00 00 00 |TMGR ........|
00000180 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 |................|
*
000001a0 00 00 00 00 00 00 00 00 00 00 00 00 0d 0a 44 69 |..............Di|
000001b0 73 6b 20 65 72 72 6f 72 ff 0d 0a 50 72 65 73 73 |sk error...Press|
000001c0 20 61 6e 79 20 6b 65 79 20 74 6f 20 72 65 73 74 | any key to rest|
000001d0 61 72 74 0d 0a 00 00 00 00 00 00 00 00 00 00 00 |art.............|
000001e0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 |................|
000001f0 00 00 00 00 00 00 00 00 ac 01 b9 01 00 00 55 aa |..............U.|
00000200
=================== hexdump -n512 -C /dev/sda3
00000000 eb 52 90 4e 54 46 53 20 20 20 20 00 02 08 00 00 |.R.NTFS .....|
00000010 00 00 00 00 00 f8 00 00 3f 00 ff 00 00 a8 08 00 |........?.......|
00000020 00 00 00 00 80 00 80 00 ff 1f 7b 2e 00 00 00 00 |..........{.....|
00000030 00 00 0c 00 00 00 00 00 02 00 00 00 00 00 00 00 |................|
00000040 f6 00 00 00 01 00 00 00 8f 5c 9f 44 6f 9f 44 4a |..........Do.DJ|
00000050 00 00 00 00 fa 33 c0 8e d0 bc 00 7c fb 68 c0 07 |.....3.....|.h..|
00000060 1f 1e 68 66 00 cb 88 16 0e 00 66 81 3e 03 00 4e |..hf......f.>..N|
00000070 54 46 53 75 15 b4 41 bb aa 55 cd 13 72 0c 81 fb |TFSu..A..U..r...|
00000080 55 aa 75 06 f7 c1 01 00 75 03 e9 dd 00 1e 83 ec |U.u.....u.......|
00000090 18 68 1a 00 b4 48 8a 16 0e 00 8b f4 16 1f cd 13 |.h...H..........|
000000a0 9f 83 c4 18 9e 58 1f 72 e1 3b 06 0b 00 75 db a3 |.....X.r.;...u..|
000000b0 0f 00 c1 2e 0f 00 04 1e 5a 33 db b9 00 20 2b c8 |........Z3... +.|
000000c0 66 ff 06 11 00 03 16 0f 00 8e c2 ff 06 16 00 e8 |f...............|
000000d0 4b 00 2b c8 77 ef b8 00 bb cd 1a 66 23 c0 75 2d |K.+.w......f#.u-|
000000e0 66 81 fb 54 43 50 41 75 24 81 f9 02 01 72 1e 16 |f..TCPAu$....r..|
000000f0 68 07 bb 16 68 52 11 16 68 09 00 66 53 66 53 66 |h...hR..h..fSfSf|
00000100 55 16 16 16 68 b8 01 66 61 0e 07 cd 1a 33 c0 bf |U...h..fa....3..|
00000110 0a 13 b9 f6 0c fc f3 aa e9 fe 01 90 90 66 60 1e |.............f`.|
00000120 06 66 a1 11 00 66 03 06 1c 00 1e 66 68 00 00 00 |.f...f.....fh...|
00000130 00 66 50 06 53 68 01 00 68 10 00 b4 42 8a 16 0e |.fP.Sh..h...B...|
00000140 00 16 1f 8b f4 cd 13 66 59 5b 5a 66 59 66 59 1f |.......fY[ZfYfY.|
00000150 0f 82 16 00 66 ff 06 11 00 03 16 0f 00 8e c2 ff |....f...........|
00000160 0e 16 00 75 bc 07 1f 66 61 c3 a1 f6 01 e8 09 00 |...u...fa.......|
00000170 a1 fa 01 e8 03 00 f4 eb fd 8b f0 ac 3c 00 74 09 |............<.t.|
00000180 b4 0e bb 07 00 cd 10 eb f2 c3 0d 0a 41 20 64 69 |............A di|
00000190 73 6b 20 72 65 61 64 20 65 72 72 6f 72 20 6f 63 |sk read error oc|
000001a0 63 75 72 72 65 64 00 0d 0a 42 4f 4f 54 4d 47 52 |curred...BOOTMGR|
000001b0 20 69 73 20 63 6f 6d 70 72 65 73 73 65 64 00 0d | is compressed..|
000001c0 0a 50 72 65 73 73 20 43 74 72 6c 2b 41 6c 74 2b |.Press Ctrl+Alt+|
000001d0 44 65 6c 20 74 6f 20 72 65 73 74 61 72 74 0d 0a |Del to restart..|
000001e0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 |................|
000001f0 00 00 00 00 00 00 8a 01 a7 01 bf 01 00 00 55 aa |..............U.|
00000200
=================== hexdump -n512 -C /dev/sda4
00000000 eb 52 90 4e 54 46 53 20 20 20 20 00 02 08 00 00 |.R.NTFS .....|
00000010 00 00 00 00 00 f8 00 00 3f 00 ff 00 00 c8 83 2e |........?.......|
00000020 00 00 00 00 80 00 80 00 ff 97 0f 00 00 00 00 00 |................|
00000030 55 a6 00 00 00 00 00 00 02 00 00 00 00 00 00 00 |U...............|
00000040 f6 00 00 00 01 00 00 00 88 7a e8 d4 a9 e8 d4 28 |.........z.....(|
00000050 00 00 00 00 fa 33 c0 8e d0 bc 00 7c fb 68 c0 07 |.....3.....|.h..|
00000060 1f 1e 68 66 00 cb 88 16 0e 00 66 81 3e 03 00 4e |..hf......f.>..N|
00000070 54 46 53 75 15 b4 41 bb aa 55 cd 13 72 0c 81 fb |TFSu..A..U..r...|
00000080 55 aa 75 06 f7 c1 01 00 75 03 e9 dd 00 1e 83 ec |U.u.....u.......|
00000090 18 68 1a 00 b4 48 8a 16 0e 00 8b f4 16 1f cd 13 |.h...H..........|
000000a0 9f 83 c4 18 9e 58 1f 72 e1 3b 06 0b 00 75 db a3 |.....X.r.;...u..|
000000b0 0f 00 c1 2e 0f 00 04 1e 5a 33 db b9 00 20 2b c8 |........Z3... +.|
000000c0 66 ff 06 11 00 03 16 0f 00 8e c2 ff 06 16 00 e8 |f...............|
000000d0 4b 00 2b c8 77 ef b8 00 bb cd 1a 66 23 c0 75 2d |K.+.w......f#.u-|
000000e0 66 81 fb 54 43 50 41 75 24 81 f9 02 01 72 1e 16 |f..TCPAu$....r..|
000000f0 68 07 bb 16 68 52 11 16 68 09 00 66 53 66 53 66 |h...hR..h..fSfSf|
00000100 55 16 16 16 68 b8 01 66 61 0e 07 cd 1a 33 c0 bf |U...h..fa....3..|
00000110 0a 13 b9 f6 0c fc f3 aa e9 fe 01 90 90 66 60 1e |.............f`.|
00000120 06 66 a1 11 00 66 03 06 1c 00 1e 66 68 00 00 00 |.f...f.....fh...|
00000130 00 66 50 06 53 68 01 00 68 10 00 b4 42 8a 16 0e |.fP.Sh..h...B...|
00000140 00 16 1f 8b f4 cd 13 66 59 5b 5a 66 59 66 59 1f |.......fY[ZfYfY.|
00000150 0f 82 16 00 66 ff 06 11 00 03 16 0f 00 8e c2 ff |....f...........|
00000160 0e 16 00 75 bc 07 1f 66 61 c3 a1 f6 01 e8 09 00 |...u...fa.......|
00000170 a1 fa 01 e8 03 00 f4 eb fd 8b f0 ac 3c 00 74 09 |............<.t.|
00000180 b4 0e bb 07 00 cd 10 eb f2 c3 0d 0a 41 20 64 69 |............A di|
00000190 73 6b 20 72 65 61 64 20 65 72 72 6f 72 20 6f 63 |sk read error oc|
000001a0 63 75 72 72 65 64 00 0d 0a 42 4f 4f 54 4d 47 52 |curred...BOOTMGR|
000001b0 20 69 73 20 63 6f 6d 70 72 65 73 73 65 64 00 0d | is compressed..|
000001c0 0a 50 72 65 73 73 20 43 74 72 6c 2b 41 6c 74 2b |.Press Ctrl+Alt+|
000001d0 44 65 6c 20 74 6f 20 72 65 73 74 61 72 74 0d 0a |Del to restart..|
000001e0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 |................|
000001f0 00 00 00 00 00 00 8a 01 a7 01 bf 01 00 00 55 aa |..............U.|
00000200
WARNING: GPT (GUID Partition Table) detected on '/dev/sda'! The util fdisk doesn't support GPT. Use GNU Parted.
=================== df -Th:
Filesystem Type Size Used Avail Use% Mounted on
/dev/sda5 ext4 23G 4.6G 18G 22% /
none tmpfs 4.0K 0 4.0K 0% /sys/fs/cgroup
udev devtmpfs 1.9G 12K 1.9G 1% /dev
tmpfs tmpfs 387M 1.4M 385M 1% /run
none tmpfs 5.0M 0 5.0M 0% /run/lock
none tmpfs 1.9G 84K 1.9G 1% /run/shm
none tmpfs 100M 84K 100M 1% /run/user
/dev/sda1 vfat 256M 30M 227M 12% /boot/efi
/dev/sda3 fuseblk 372G 67G 305G 19% /media/tati/OS
/dev/sda4 fuseblk 499M 330M 170M 66% /mnt/boot-sav/sda4
=================== fdisk -l:
Disk /dev/sda: 1000.2 GB, 1000204886016 bytes
255 heads, 63 sectors/track, 121601 cylinders, total 1953525168 sectors
Units = sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 4096 bytes
I/O size (minimum/optimal): 4096 bytes / 4096 bytes
Disk identifier: 0x796f89eb
Device Boot Start End Blocks Id System
/dev/sda1 1 1953525167 976762583+ ee GPT
Partition 1 does not start on physical sector boundary.
=================== Suggested repair
The default repair of the Boot-Repair utility would reinstall the grub-efi-amd64-signed of sda5, using the following options: sda1/boot/efi,
Additional repair would be performed: unhide-bootmenu-10s use-standard-efi-file
=================== Final advice in case of suggested repair
Les fichiers de démarrage de [L'OS actuellement utilisé - Ubuntu 14.04.3 LTS] sont loin du début du disque. Votre BIOS pourrait ne pas les détecter. Vous voudrez peut-être re-essayer après avoir créé une partition /boot (EXT4, >200MB, en début de disque). Cela peut être réalisé via des outils tels que gParted. Puis sélectionnez cette partition via l'option [Partition /boot séparée :] de [Boot-Repair]. (http://doc.ubuntu-fr.org/tutoriel/partition_boot)
Si votre ordinateur redémarre directement sur Windows, essayez de changer l'ordre de démarrage dans votre BIOS.
Si votre BIOS ne permet pas de changer l'ordre de démarrage, changez l'entrée de démarrage par défaut de l'amorceur Windows.
Par exemple, vous pouvez démarrer Windows, puis saisir la commande suivante dans une invite de commande en mode administrateur :
bcdedit /set {bootmgr} path \EFI\...\grub*.efi
=================== User settings
The settings chosen by the user will not act on the boot.
C'est parfait jusque là. Est-ce que tu souhaites ajouter une partition de stockage commune appelée Partition de partage de données avec Windows dans la doc. Ou bien est-ce que tu as un autre projet pour le stockage de tes données ?
Hors ligne
#46 Le 07/01/2016, à 22:25
- filipino
Re : [Résolu] Installation dualboot sur laptop sous wds10
Non merci, je pense que l'espace wds sera dédié aux qq fichiers necessitant les logiciels wds, pour le reste, je vais utiliser avant tout ubuntu; d'ailleurs, je n'avais pas réussi à faire fonctionner une enceinte bluetoth sous wds et là ça marche en deux coups de cuillère à pot! Je suis content, merci
ps : je pensai trouver des posts relatifs à la finalisation, per ex quid de "ubuntu-restricted-extras" etc ?
Dernière modification par filipino (Le 07/01/2016, à 22:26)
Laptop ASUS X751LAV-TY481T
XUbuntu 18.04 LTS- 64 bits - i3 - 4005U-1.70ghz
Hors ligne
#47 Le 08/01/2016, à 08:17
- malbo
Re : [Résolu] Installation dualboot sur laptop sous wds10
Extrait du Boot-Info du post #45 :
=================== parted -l:
Model: ATA TOSHIBA MQ01ABD1 (scsi)
Disk /dev/sda: 1000GB
Sector size (logical/physical): 512B/4096B
Partition Table: gpt
Number Start End Size File system Name Flags
1 1049kB 274MB 273MB fat32 EFI system partition boot
2 274MB 290MB 16.8MB Microsoft reserved partition msftres
3 290MB 400GB 399GB ntfs Basic data partition msftdata
4 400GB 400GB 523MB ntfs Basic data partition hidden, diag
5 400GB 425GB 25.0GB ext4
6 425GB 430GB 5000MB linux-swap(v1)
On y voit que les 6 partitions actuelles occupent 430 Go sur ton disque dur de 1000 Go. Il y a donc 570 Go non alloués (c'est à dire non occupés par une partition). Est-ce que tu l'as fait exprès de laisser ce "trou" de 570 Go parce que tu prévois des installations futures d'autres distributions ou bien est-ce pour une autre raison ?
Dernière modification par malbo (Le 08/01/2016, à 08:18)
Hors ligne
#48 Le 08/01/2016, à 11:19
- filipino
Re : [Résolu] Installation dualboot sur laptop sous wds10
Oui, en effet, je n'ai pas fait attention mais c'est censé être ma partition pour ubuntu, il me semblait qu'a la derniere etape du tuto d'install ça mettait ça en ext4
Laptop ASUS X751LAV-TY481T
XUbuntu 18.04 LTS- 64 bits - i3 - 4005U-1.70ghz
Hors ligne
#49 Le 08/01/2016, à 11:45
- malbo
Re : [Résolu] Installation dualboot sur laptop sous wds10
A l'étape 3 du tuto, tu as dû oublier de réfléchir et tu t'es laissé embarquer par le passage qui disait "La partition home n'est pas obligatoire, c'est l' équivalent du disque D:\DATA sous Windows.". En effet, tu n'as pas créé de partition /home - alors même que le tuto détaillait la création de cette partition home - mais quand on ne crée pas de partition /home, on est sensé occuper toute la place disponible par la partition racine (oui, ce n'est pas écrit noir sur blanc dans le tuto ou plutôt c'est formulé maladroitement dans le tuto (**) mais bon....). Moi, je te conseillerais soit de refaire toute l'installation de Ubuntu en créant une partition /home, soit de réaménager ton installation actuelle de Ubuntu (*) en augmentant la taille de ta partition racine pour qu'elle occupe le maximum de place.
(*) ça se fait avec Gparted depuis une session live.
(**) la figure ici extraite de ce tuto emploie le terme "partition libre" pour désigner en fait un espace non-alloué.
Dernière modification par malbo (Le 08/01/2016, à 11:57)
Hors ligne
#50 Le 08/01/2016, à 12:08
- filipino
Re : [Résolu] Installation dualboot sur laptop sous wds10
En effet, ça me semblait bizarre ce passage; donc si je refais une install, cet espace libre je le monte en /home, et quel est l'interet/difference entre tes deux solutions?
Laptop ASUS X751LAV-TY481T
XUbuntu 18.04 LTS- 64 bits - i3 - 4005U-1.70ghz
Hors ligne
